LINK II MOD III SYSTEM
LINK II MOD III SYSTEM
Product category :Naval Communication Systems
- Naval Tactical Data Link System (L2M3) provides a Data Exchange network used by Ships, Submarines and Shore Establishments to exchange their tactical picture in near-real time. The exchange can be mutual or to Maritime Operations Centers.
- Data Link System((L2M3) also supports the exchange of text messages, imagery data using media like Tactical Radio, MSS, SATCOM. etc.
- System is designed to have seamless integration with CMS interface & capable of exchanging voice and video along with the tactical and messaging information.
Features
- Communication through SDR NC & TAC Radios
- Interfacing with onboard systems Like CMS,MSS etc
- Exchange of Tactical and Messaging information
LINK II MODI II Consists of Following Subsystems
- Main Processor Unit (MPU) :The main processor unit acts as the server in Server-Client architecture and caters to all server functionalities as required by the application software sub-system. System level redundancy is built at this layer with two servers in hot standby. The main Application Layer will reside on this system.
- Radio Modem Unit: It comprises of four channels Radio Modem that is interfaced with on-board legacy communication systems. The modem channels are connected to the HF and V/UHF communication sets
- Messaging Consoles: The Messaging consoles are on the LAN and will be connected to the MPU by Console Gigabit Ethernet/FO via the central Ethernet switch. The Messaging console is used for generating free text messages or situation reports etc., by the operators and also viewing the received messages.
- Tactical Consoles: The Tactical Consoles are on the LAN and will be connected to the MPU by Console Gigabit Ethernet/FO via the central Ethernet switch. The Tactical Console is used for viewing the tactical information.
- Mobile Messaging Console: The portable Wi-Fi enabled Mobile Messaging Console are also part of the LAN and are connected by 802 point11g based APs. The Messaging console is used for generating free text messages/situation reports etc., by the operators and also viewing the received messages.
